NOU
Placa de baza Gigabyte A520M DS3H V2, Socket AM4, DDR4, Micro-ATX
340,99 RON
Costurile de livrare nu sunt incluse
Descriere
Placa de baza GIGABYTE A520M DS3H V2 AM4, 4x DDR4, 1x DP 1x HDMI, 1 PCIE x16 1x PCIE x1, 1x M.2, 4x SATA 6gb/s
Detalii
SKU
A520M DS3H V2
Categorii
Brand
Lithium weight per battery
0.07 g
Battery type
CR2032
Clear CMOS button
Yes
ACPI version
5.0
Desktop Management Interface (DMI) version
2.7
System Management BIOS (SMBIOS) version
2.7
BIOS type
UEFI AMI
BIOS memory size
128 Mbit
Clear CMOS jumper
Yes
Number of M.2 (M) slots
1
PCI Express x16 (Gen 3.x) slots
1
Motherboard form factor
micro ATX
PC health monitoring
CPU, LED, Power supply, Temperature, Voltage
Power source type
ATX
Motherboard chipset family
AMD
Audio output channels
7.1 channels
Maximum resolution
5120 x 2880 pixels
Front panel connector
Yes
TPM connector
Yes
12V power connector
Yes
USB 2.0 connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
Serial port headers
1
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
Number of SATA III connectors
4
Front panel audio connector
Yes
ATX Power connector (24-pin)
Yes
CPU fan connector
Yes
Number of memory slots
4
Memory slots type
DIMM
Unbuffered memory
Yes
Supported memory types
DDR4-SDRAM
Supported memory clock speeds
2133,2400,2667,2933,3200,3333,3600,4000,4400,4733 MHz
ECC сompatibility
ECC & Non-ECC
Ethernet interface type
Gigabit Ethernet
DVI-D ports quantity
1
Processor socket
Socket AM4
Supported processor sockets
Socket AM4
Compatible processor series
AMD Ryzen 3000 Series, AMD Ryzen Threadripper 3000 Series, AMD Ryzen Threadripper PRO 3000 WX-Series
Supported storage drive types
HDD & SSD
Number of HDDs supported
4
Number of storage drives supported
5
PCI Express x1 (Gen 3.x) slots
2
PS/2 ports quantity
1
Maximum number of SMP processors
1
Number of SATA II connectors
0
Number of displays supported
3
Maximum internal memory supported by processor
128 GB
Total number of SATA connectors
4
Digital audio optical out
1
Drivers included
Yes
Number of EATX power connectors
1
Power fan connector
Yes
Supported memory module capacities
1GB, 2GB, 4GB, 8GB, 16GB, 32GB
Number of Parallel ATA connectors
0
eSATA ports quantity
0
Firewire (IEEE 1394) ports
0
Discrete graphics support
Yes
Microphone in
Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
DisplayPort version
2.0
DisplayPorts quantity
1
HDCP
Yes
Headphone outputs
1
VGA (D-Sub) ports quantity
0
Windows operating systems supported
Windows 10 x64
Cables included
SATA
Width
244 mm
Height
35 mm
Package width
265 mm
Package height
54 mm
Depth
24.4 mm
Package weight
810 g
Package depth
265 mm
Country of origin
China
Bundled software
Norton Internet Security (OEM version), Realtek 8118 Gaming LAN Bandwidth Control Utility
PCI
0
Serial-or-Paralel
No/No
Onboard-CPU
No
Cooling type
Active
Component for
PC
RAID support
Yes
RAID levels
0, 1, 10
Memory channels
Dual-channel
Ethernet LAN
Yes
Processor manufacturer
AMD
Battery technology
Lithium-Manganese Dioxide (LiMnO2)
Maximum internal memory
128 GB
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
HDMI ports quantity
1
HDMI version
2.1
Number of battery cells
1
Battery weight
3 g
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
USB 2.0 ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
Audio Chip
Realtek ALC887
USB connector type
USB Type-A
Supported storage drive interfaces
M.2, SATA III
Wi-Fi
No
