WWAN controller
Quectel RM520N-GL
Total processor performance up to
115 TOPs
USB Type-C charging port
Yes
GPU performance up to
64 TOPs
USB Power Delivery (USB PD)
Yes
Near Field Communication (NFC)
No
Operating system installed
Windows 11 Pro
Keyboard language
English
Touchscreen
On-cell, 10-point Multi-touch
Housing material
Aluminium, Carbon fibre
Card reader integrated
No
Bundled software
Intel Connectivity Performance Suite + Lenovo AI Now
Certification
Eyesafe
MIL-STD-810H
TCO 9
Zoom Certified – Premium Laptop
Operating temperature (T-T)
5 - 35 C
Storage temperature (T-T)
5 - 43 C
Chipset
Intel SoC Platform
M.2 SSD size
2280 (22 x 80 mm)
Storage relative humidity (H-H)
5 - 95%
Operating relative humidity (H-H)
8 - 95%
Internal memory type
LPDDR5x-SDRAM
Memory form factor
On-board
Memory clock speed
8533 MHz
Memory channels
Dual-channel
Total storage capacity
2 TB
Processor family
Intel Core Ultra 7
Processor manufacturer
Intel
On-board graphics card model
Intel Arc Graphics 140V
On-board GPU manufacturer
Intel
Mobile network connection
Yes
Pointing device
ThinkPad UltraNav
Battery technology
Lithium-Ion (Li-Ion)
AC adapter input voltage
100 - 240 V
Front camera HD type
Ultra HD
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
AC adapter frequency
50/60 Hz
On-board graphics card family
Intel Arc Graphics
Maximum shipping altitude
3048 m
Processor generation
Intel Core Ultra (Series 2)
Mobile network generation
5G
Wi-Fi standards
Wi-Fi 7 (802.11be)
Display brightness
500 cd/m
Maximum refresh rate
60 Hz
Contrast ratio (typical)
1000:1
Number of built-in speakers
2
Thunderbolt 4 ports quantity
2
Display diagonal
35.6 cm (14)
Display resolution
1920 x 1200 pixels
Native aspect ratio
16:10
Combo headphone/mic port
Yes
Market positioning
Premium
Processor boost frequency
4.8 GHz
Low Power Efficient-cores
4
Performance-core Max Turbo Frequency
4.8 GHz
Low Power Efficient-core Base Frequency
2200 MHz
Processor cache type
Smart Cache
Neural processor unit (NPU)
Intel AI Boost
Windows Studio effects support
Yes
AI software frameworks supported by NPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Maximum internal memory
32 GB
Memory slots
Memory soldered to systemboard, no slots, dual-channel
Number of SSDs installed
1
SSD interface
PCI Express 5.0
On-board graphics card
Yes
Front camera resolution (numeric)
8 MP
Privacy type
Privacy shutter
WLAN controller model
Intel Wi-Fi 7 BE201
WLAN controller manufacturer
Intel
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB Type-C DisplayPort Alternate Mode
Yes
Cable lock slot type
Kensington
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Low Power Efficient-core Max Turbo Frequency
3.7 GHz
Performance-core base frequency
2.2 GHz
Processor base power
17 W
Discrete graphics card
No
Discrete graphics card model
Not available
Sustainability certificates
ENERGY STAR, EPEAT Gold, Forest Stewardship Council (FSC)
Motherboard chipset
Intel SoC
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
Operating System
Windows 11 Pro, Romanian / English
Audio Chip
Realtek ALC713
Green Certifications
ENERGY STAR 8.0
Display
14 WUXGA (1920x1200) IPS 500nits Anti-glare, 100% sRGB, 60Hz, Low Power, Touch
Case Material
Carbon Fiber (Top), Aluminium (Bottom)
Other Certifications
Eyesafe Certified 2.0
Dimensions (WxDxH)
312.80 x 214.75 x 8.38/14.77 (front/rear), 17.95 (maximum) mm;
12.31 x 8.45 x 0.33/0.58 (front/rear), 0.71 (maximum)inches
Standard Ports
1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
Graphics
Integrated Intel Arc™ Graphics 140V
Speakers
Stereo speakers, 2W x2, Dolby Atmos
Power Adapter
65W USB-C Slim GaN (3-pin)
Memory
32GB Soldered LPDDR5x-8533, MoP Memory
Camera
UHD 8.0MP + IR Discrete with Privacy Shutter, MIPI, Computer Vision
Storage Slot
Models with V or H series processor: one M.2 2280 PCIe 5.0 x4 slot
Max Memory
32GB soldered memory, not upgradable
Storage
2TB SSD M.2 2280 PCIe 5.0x4 Performance NVMe Opal 2.0
Other Security
Camera privacy shutter
Processor
Intel Core™ Ultra 7 258V, 8C (4P + 4LPE) / 8T, Max Turbo up to 4.8GHz, 12MB
Ethernet
No Onboard Ethernet
WLAN + Bluetooth
Intel Wi-Fi 7 BE201, 802.11be 2x2 + BT5.4
Security Chip
Discrete TPM 2.0 Enabled
Mil-Spec Test
MIL-STD-810H military test passed
Keyboard
Backlit, English (EU)
AI PC Category
Copilot+ PC
NPU
Integrated Intel AI Boost, up to 47 TOPS
Storage Support
One drive, up to 2TB M.2 2280 SSD
Base Warranty
3-year, Courier or Carry-in
Operating system language
English, ROM
Physical Locks
Kensington Nano Security Slot, 2.5 x 6 mm
System Management
Non-vPro
Optional Ports (configured)
1x Nano-SIM Card Slot
Spill-resistant keyboard
Yes
USB Sleep-and-Charge ports
1
Password protection type
BIOS, Power on, Supervisor
NPU performance up to
47 TOPs
